Wire Harness - Z15vdk99aa/Au (49Rgrharness151000aa) replacement parts for 2015 Polaris RZR XP 1000

OEM Parts Polaris 2015 Polaris RZR XP 1000 Wire Harness - Z15vdk99aa/Au (49Rgrharness151000aa)

Wire Harness - Z15VDK99AA/AU (49RGRHARNESS151000AA) Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	HARNESS-GPS, RECEIVER, MFD, RZN Part #: 2412817 Required per assembly: 1 Currently Not Available
2	HARNESS-USB, MFD, RZN Part #: 2412818 Required per assembly: 1 Currently Not Available
3	HARNESS-CHASSIS, EPS, RZN, 64 Part #: 2413232 Required per assembly: 1 Note: INCL. 24-33 Currently Not Available
4	HARNESS-BOX, RZN, 64 Part #: 2412884 Required per assembly: 1 Currently Not Available
5	GPS-ANTENNA, RECEIVER, CAN Part #: 4014811 Required per assembly: 1 Currently Not Available
6	GROMMET, ELECTRICAL Part #: 5414440 Required per assembly: 1 Currently Not Available
7	SCREW Part #: 7518533 Required per assembly: 4 Note: Screw, Flange Currently Not Available
8	NUT Part #: 7547274 Required per assembly: 1 Note: Nut, Flange Currently Not Available
9	KIT, IGNITION, COIL Part #: 2876049 Required per assembly: 1 Note: Coil Currently Not Available
10	JUMPER, COIL, GROUND Part #: 4014422 Required per assembly: 1 Currently Not Available
11	SPACER, COIL Part #: 5436577 Required per assembly: 1 Note: Spacer, Coil Mount Currently Not Available
12	SCREW Part #: 7518780 Required per assembly: 1 Currently Not Available
13	ECM Part #: 4014125 Required per assembly: 1 Currently Not Available
14	SCREW Part #: 7519091 Required per assembly: 4 Currently Not Available
15	NUTS-10-32 KEPS Part #: 7547341 Required per assembly: 3 Currently Not Available
16	BLOCK, TERMINAL Part #: 4011892 Required per assembly: 1 Note: Block, Terminal Currently Not Available
17	SCREW Part #: 7518196 Required per assembly: 2 ~~$1.99~~ $1.15 - + Add to cart
18	REGULATOR, 3PH, 50A, SERIES, HISPD, TCAP Part #: 4015229 Required per assembly: 1 Currently Not Available
19	PLATE-HEAT SINK REGULATOR Part #: 5254970 Required per assembly: 1 Currently Not Available
20	NUT, FLANGE Part #: 7547339 Required per assembly: 2 Currently Not Available
21	HARNESS-DASH, LIGHT, RZN Part #: 2412608 Required per assembly: 1 Currently Not Available
22	CABLE-ACCY, BATT, TO, TERM, BLOCK Part #: 4015217 Required per assembly: 1 Currently Not Available
23	STRAP, PANDUIT, 14" Part #: 7080761 Required per assembly: 2 Note: Cable Tie Currently Not Available
24	STRAP, PANDUIT, DOUBLE, LOOP Part #: 7081916 Required per assembly: 7 Currently Not Available
25	LABEL-FUSE BOX Part #: 7180884 Required per assembly: 1 Currently Not Available
26	CLIP-ROUTING, DIN, BOX Part #: 7082020 Required per assembly: 1 Currently Not Available
27	CLIP-ROUTING Part #: 7081496 Required per assembly: 18 Currently Not Available
28	COVER, DIAGNOSTIC, W/CLIP Part #: 4012170 Required per assembly: 1 Currently Not Available
29	BREAKER, CIRCUIT, 20, AMP Part #: 4011372 Required per assembly: 1 Currently Not Available
30	RELAY-SPST, 12V, 20A, EPXY, HFA Part #: 4016819 Required per assembly: 5 Currently Not Available
31	FUSE-20 MINI BLADE 58V(YELLOW) Part #: 4012811 Required per assembly: 2 Currently Not Available
32	FUSE, 10AMP Part #: 2434016 Required per assembly: 7 Note: Fuse, 10 AMP, Ignition Sold in multiples of 10 only Currently Not Available
33	LED-PANEL, MNT, 12V, BLUE Part #: 2413217 Required per assembly: 1 Currently Not Available
