Drive Train, Transmission replacement parts for 2012 Polaris Phoenix 200 (A12PB20AF)

OEM Parts Polaris 2012 Polaris Phoenix 200 (A12PB20AF) Drive Train, Transmission

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	CLIP, RETAINER Part #: 0452339 Required per assembly: 2 Note: Clip, Cir Currently Not Available
2	BEARING, BALL Part #: 0452349 Required per assembly: 1 Currently Not Available
3	GEAR, FINAL, RING Part #: 0452531 Required per assembly: 1 Currently Not Available
4	SHAFT Part #: 0452528 Required per assembly: 1 Currently Not Available
5	GEAR Part #: 0452530 Required per assembly: 1 Currently Not Available
6	CLIP, CIR Part #: 0453779 Required per assembly: 1 Currently Not Available
7	SHAFT, DRIVE Part #: 0452525 Required per assembly: 1 Currently Not Available
8	WASHER, FLAT Part #: 0452524 Required per assembly: 1 $3.33 $2.40 - + Add to cart
9	CIRCLIP, EXTERNAL Part #: 0450187 Required per assembly: 1 Note: Circlip Currently Not Available
10	COLLAR, SHAFT Part #: 0453120 Required per assembly: 1 Currently Not Available
11	BUSHING Part #: 0452516 Required per assembly: 1 Currently Not Available
12	WASHER, FLAT Part #: 0452513 Required per assembly: 2 Currently Not Available
14	RATCHET, SHIFT Part #: 0452517 Required per assembly: 1 Currently Not Available
15	RING, RETAINER Part #: 0452789 Required per assembly: 1 Note: Clip, Cir Currently Not Available
16	WASHER, SPLINE Part #: 0452518 Required per assembly: 1 Currently Not Available
17	BEARING, NEEDLE Part #: 0452521 Required per assembly: 1 Currently Not Available
19	WASHER, FLAT Part #: 0452522 Required per assembly: 1 $10.99 $6.33 - + Add to cart
20	SHAFT, TRANSMISSION Part #: 0453551 Required per assembly: 1 Currently Not Available
21	GEAR, COUNTER Part #: 0452527 Required per assembly: 1 $114.99 $59.52 - + Add to cart
22	SHAFT, COUNTER Part #: 0452526 Required per assembly: 1 Currently Not Available
23	ASSEMBLY, REVERSE, GEAR Part #: 0452519 Required per assembly: 1 Note: Asm., Reverse Gear [Incl. 17,18] Currently Not Available
24	ASSEMBLY, SPUR, GEAR Part #: 0454229 Required per assembly: 1 Note: Asm., Spur Gear [Incl. 11,13] Currently Not Available
25	ROLLER, DRUM, SENSOR Part #: 0452163 Required per assembly: 1 Currently Not Available
26	SPRING, DRUM, SENSOR Part #: 0452162 Required per assembly: 1 Currently Not Available
27	SPINDLE, TRANSMISSION Part #: 0454230 Required per assembly: 1 Currently Not Available
28	E-CLIP Part #: 0452161 Required per assembly: 1 Currently Not Available
29	ASSEMBLY, DRUM, GEAR, SHIFT Part #: 0454231 Required per assembly: 1 Currently Not Available
30	FORK, SHIFT Part #: 0452157 Required per assembly: 1 Currently Not Available
31	SHAFT, GEAR, SHIFT Part #: 0452158 Required per assembly: 1 Currently Not Available
