Electrical Parts replacement parts for 2012 Polaris Phoenix 200 (A12PB20AF)

OEM Parts Polaris 2012 Polaris Phoenix 200 (A12PB20AF) Electrical Parts

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	BOLT, HEX, WASHER, FACE Part #: 0452917 Required per assembly: 2 Note: Bolt Currently Not Available
2	BOLT, HEX, WASHER, FACE Part #: 0450701 Required per assembly: 2 Note: Bolt Sold in multiples of 10 only Currently Not Available
3	RECTIFIER/REGULATOR-PHOENIX Part #: 0455311 Required per assembly: 1 Currently Not Available
4	BRACKET, ELECTRICAL Part #: 0452764 Required per assembly: 1 Currently Not Available
5	ASSEMBLY, CDI Part #: 0454244 Required per assembly: 1 Note: Asm., CDI [Incl. 6] Currently Not Available
6	PAD, RUBBER Part #: 0453473 Required per assembly: 1 Currently Not Available
8	ASSEMBLY, POUCH, TOOL Part #: 0454245 Required per assembly: 1 Currently Not Available
9	STRAP Part #: 0450721 Required per assembly: 1 $2.99 $1.73 - + Add to cart
10	ASM-HARNESS, MAIN, PHOENIX, TXL Part #: 0455416 Required per assembly: 1 Currently Not Available
11	FUSE, MAIN, HARNESS Part #: 0452744 Required per assembly: 1 Currently Not Available
12	NUT, LOCK Part #: 0450150 Required per assembly: 2 Note: Nut, Flange $1.99 $1.15 - + Add to cart
13	ASSEMBLY, STARTER, RELAY Part #: 0452761 Required per assembly: 1 Currently Not Available
14	STRAP Part #: 0450559 Required per assembly: 11 $1.99 $1.15 - + Add to cart
15	BATTERY Part #: 4011434 Required per assembly: 1 Currently Not Available
16	ASSEMBLY, BATTERY, CABLE Part #: 0452767 Required per assembly: 1 Currently Not Available
17	INDICATOR-NEUTRAL Part #: 0454669 Required per assembly: 1 Currently Not Available
18	INDICATOR-REVERSE PHX Part #: 0454670 Required per assembly: 1 Currently Not Available
19	BOLT Part #: 0452763 Required per assembly: 1 Currently Not Available
20	CAP, SPARK, PLUG Part #: 0453364 Required per assembly: 1 Currently Not Available
21	ASSEMBLY, IGNITION, COIL Part #: 0452309 Required per assembly: 1 Currently Not Available
22	CABLE, ETC, CONNECTING Part #: 0453144 Required per assembly: 1 Currently Not Available
23	CLIP, MAIN, SWITCH Part #: 0450886 Required per assembly: 1 Currently Not Available
24	ASSEMBLY, SWITCH, MAIN Part #: 0453415 Required per assembly: 1 Currently Not Available
25	KEY, BLANK, RH, GROOVE Part #: 0453143 Required per assembly: 1 Note: Key, Blank, RH Currently Not Available
25	KEY, BLANK, LH, GROOVE Part #: 0453372 Required per assembly: 1 Note: Key, Blank, LH Currently Not Available
26	STRAP, BATTERY, RUBBER Part #: 0452660 Required per assembly: 1 Currently Not Available
