2012 Polaris RZR 4 XP 900 R12XT87AA/9EAS - Dash Instruments And Controls

DASH INSTRUMENTS and CONTROLS Full screen diagram
Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
1

ASM-CLUSTER, CPIA3, SXS, ESIN, L

Part #: 3280623 Required per assembly: 1
Currently Not Available
2

BEZEL-INSTRUMENT CLUSTER

Part #: 5438945 Required per assembly: 1
Currently Not Available
3

RECEPTACLE, POD, MOUNT, 12V

Part #: 4012393 Required per assembly: 2
Currently Not Available
4

SWITCH-HEADLIGHT SEALED

Part #: 4012909 Required per assembly: 1
Currently Not Available
5

SWITCH-AWD RANGER SEALED

Part #: 4012908 Required per assembly: 1
Currently Not Available
6

SWITCH, KEY

Part #: 4012165 Required per assembly: 1 Note: 3 position. Comes with 2 keys. 6 Pin
Currently Not Available
