2012 Polaris RZR 4 XP 900 R12XT87AA/9EAS - Front Caliper

FRONT CALIPER Full screen diagram
Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
-

ASSEMBLY, CALIPER, BRAKE, DOUBLE, BORE, LH

Part #: 1911283 Required per assembly: 1 Note: Incl. 1-10
Currently Not Available
-

ASSEMBLY, CALIPER, DOUBLE, BORE, BRAKE, RH

Part #: 1911284 Required per assembly: 1 Note: Incl. 1-10
Currently Not Available
1

SCREW, BLEEDER

Part #: 7081343 Required per assembly: 1
Currently Not Available
2

SCREW, SOCKET, SET

Part #: 7518863 Required per assembly: 1
Currently Not Available
4

KIT, BOOT, F.BRAKE

Part #: 1930642 Required per assembly: 1 Note: Incl. 5,6
Currently Not Available
4

KIT, BOOT, F.BRAKE

Part #: 1930642 Required per assembly: 1 Note: Incl. 5,6
Currently Not Available
5

BOOT, BUSHING

Part #: 5412505 Required per assembly: 1
Currently Not Available
6

BOOT, PIN, SEAL

Part #: 5412506 Required per assembly: 1
Currently Not Available
7

SEAL, CALIPER, INNER

Part #: 5412907 Required per assembly: 4
Currently Not Available
7

SEAL, CALIPER, INNER

Part #: 5412907 Required per assembly: 4
Currently Not Available
8

PISTON, CALIPER

Part #: 5135134 Required per assembly: 2
Currently Not Available
11

SCRAPER-BRAKE FRONT

Part #: 5438948 Required per assembly: 2
Currently Not Available
12

SCREW

Part #: 7516823 Required per assembly: 4
Currently Not Available
