Main Frame And Skid Plate replacement parts for 2019 Polaris RZR 1000S4 (R04)

OEM Parts Polaris 2019 Polaris RZR 1000S4 (R04) Main Frame And Skid Plate

MAIN FRAME AND SKID PLATE Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	WELD-MAINFRAME, FRT, MP, SWY, BLK Part #: 1024538-458 Required per assembly: 1 Currently Not Available
2	WELD-MAINFRAME, REAR.BLK Part #: 1024233-458 Required per assembly: 1 Currently Not Available
3	ASM-TUBE, TOP, FRAME, ECOAT Part #: 1024407-329 Required per assembly: 1 Currently Not Available
4	WELD-DASH, E-COAT, BLK Part #: 1020984-329 Required per assembly: 1 Currently Not Available
5	WELD-SEAT, BASE, MP, BLK Part #: 1020572-329 Required per assembly: 1 Currently Not Available
6	WELD-MOUNT, BODY, M.BLK Part #: 1020506-458 Required per assembly: 2 Currently Not Available
7	BASE, SEAT, REAR, BLACK Part #: 1019777-329 Required per assembly: 1 Currently Not Available
8	PLATE-SKID, BLK Part #: 5451895-070 Required per assembly: 1 Currently Not Available
9	PLATE-SKID, REAR, BLK Part #: 5456433-070 Required per assembly: 1 Currently Not Available
10	PLATE-SKID, BLK Part #: 5439771-070 Required per assembly: 1 Currently Not Available
11	TIEDOWN, FRONT, RH, BLK Part #: 5263590-458 Required per assembly: 1 Currently Not Available
12	BRKT-SUSP, MNT, FRT, M.BLK Part #: 5259449-458 Required per assembly: 1 Currently Not Available
13	MOUNT, COIL, E-COAT Part #: 5259105-329 Required per assembly: 1 Currently Not Available
14	TIEDOWN, FRONT, LH, M.BLK Part #: 5259103-458 Required per assembly: 1 Currently Not Available
15	BRACKET, SEAT, SUPPORT, FRONT, MP, BLACK Part #: 5258097-329 Required per assembly: 2 Currently Not Available
16	BRACKET, DIN, MOUNT, BLACK Part #: 5257304-329 Required per assembly: 1 Currently Not Available
17	WASHER-SKID PLATE Part #: 7556065 Required per assembly: 14 Note: Washer Currently Not Available
18	NUT, U-TYPE Part #: 7547674 Required per assembly: 2 ~~$2.99~~ $1.73 - + Add to cart
19	NUT, FLANGE Part #: 7547339 Required per assembly: 1 Currently Not Available
20	NUT, FLANGE Part #: 7547333 Note: M10 x 1.25 ~~$3.74~~ $2.23 - + Add to cart
21	NUT, FLANGE Part #: 7547332 Required per assembly: 4 Note: Nut, Nylok Currently Not Available
22	SCREW Part #: 7519650 Required per assembly: 4 Currently Not Available
23	SCR-HXFL-M10X1.25X40 8.8 ZOD Part #: 7519332 Required per assembly: 2 Currently Not Available
24	SCR-HXFL-M10X1.25X55 10.9 ZOD Part #: 7519285 Required per assembly: 10 Currently Not Available
25	SCREW Part #: 7518934 Required per assembly: 4 Currently Not Available
26	SCREW Part #: 7518555 Note: Bolt, Flange Currently Not Available
27	SCREW Part #: 7518529 ~~$2.99~~ $1.73 - + Add to cart
28	SCREW, FLANGE Part #: 7518474 Required per assembly: 2 Note: Bolt ~~$5.99~~ $2.30 - + Add to cart
29	SCREW, FLANGE Part #: 7517281 Required per assembly: 4 Note: Screw Currently Not Available
30	SHIELD-BOX MOUNT Part #: 5262036 Required per assembly: 1 Currently Not Available
31	PLUNGER, BOX, LATCH Part #: 5139009 Required per assembly: 1 Currently Not Available
