Dash - R151dpd1aa/2D (49Brutusdash13) replacement parts for 2015 Polaris Ranger HST

OEM Parts Polaris 2015 Polaris Ranger HST Dash - R151dpd1aa/2D (49Brutusdash13)

Dash - R151DPD1AA/2D (49BRUTUSDASH13) Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	BRACKET, MOUNT Part #: 5258201 Required per assembly: 2 Currently Not Available
2	BRACKET, DASH, MOUNT Part #: 5258205 Required per assembly: 1 Currently Not Available
3	GROMMET Part #: 5412504 Required per assembly: 1 Currently Not Available
4	DASH, STORAGE, BLACK Part #: 5439017-070 Required per assembly: 1 Note: 1D Currently Not Available
4	DASH, STORAGE, ROUTERED, BLACK Part #: 5439824-070 Required per assembly: 1 Note: 2D Currently Not Available
5	U-TYPE, SPEED, NUT Part #: 7081305 Required per assembly: 8 Note: Clip, U Speed Nut [Built 12/07/09 and Before] Currently Not Available
6	SCREW Part #: 7518529 Required per assembly: 6 $2.99 $1.73 - + Add to cart
7	SCREW Part #: 7519045 Required per assembly: 4 Currently Not Available
8	SCREW Part #: 7519650 Required per assembly: 9 Currently Not Available
9	PLUG, HOLE Part #: 7080416 Required per assembly: 1 $5.99 $3.45 - + Add to cart
10	GROMMET, SHIFT, LEVER Part #: 5414249 Required per assembly: 1 Currently Not Available
11	HOLDER, CUP Part #: 5436836 Required per assembly: 2 Currently Not Available
12	DASH, PANEL, LOWER, SAGEBRUSH, GREEN, METALLIC Part #: 5439015-498 Required per assembly: 1 Note: 1D Currently Not Available
13	PANEL, DASH, CONTROLS, BLACK Part #: 5439013-070 Required per assembly: 1 Note: 1D $44.99 $33.52 - + Add to cart
13	PANEL, DASH, CONTROLS, ROUTER, BLACK Part #: 5439585-070 Required per assembly: 1 Note: 2D Currently Not Available
14	COVER, GLOVEBOX, SAGEBRUSH, GREEN, METALLIC Part #: 5439019-498 Required per assembly: 1 Currently Not Available
15	SEAL, GLOVEBOX Part #: 5521937 Required per assembly: 1 Currently Not Available
16	SCREW Part #: 7512026 Required per assembly: 6 Note: Screw Currently Not Available
17	RIVET Part #: 7661855 Required per assembly: 7 $2.99 $1.73 - + Add to cart
18	DASH, PANEL, UPPER, BLACK Part #: 5439014-070 Required per assembly: 1 Note: 1D Currently Not Available
18	DASH-PANEL, UPPER, ROUTERED, BLK Part #: 5451067-070 Required per assembly: 1 Note: 2D Currently Not Available
19	COVER, HVAC, BLACK Part #: 5439648-070 Required per assembly: 1 Note: 2D Currently Not Available
