Steering Asm. - T16aas/Aap All Options (49Slingshotsteer14sling) replacement parts for 2016 Polaris Slingshot All Options

OEM Parts Polaris 2016 Polaris Slingshot All Options Steering Asm. - T16aas/Aap All Options (49Slingshotsteer14sling)

Steering Asm. - T16AAS/AAP All Options (49SLINGSHOTSTEER14SLING) Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	BADGE-SLINGSHOT, FIN Part #: 7179350 Required per assembly: 1 Currently Not Available
2	HORN PAD Part #: 5451358 Required per assembly: 1 Currently Not Available
3	WHEEL-STEERING Part #: 1824215 Required per assembly: 1 Currently Not Available
4	NUT-HEX-M16X2 8 ZC NYL Part #: 7547506 Required per assembly: 1 Currently Not Available
5	MODULE-CLOCK, SPRING, 2, CKT Part #: 4016020 Required per assembly: 1 Currently Not Available
6	SCR-SOCHD, M5X.8, 12, 0600084 Part #: 7518811 Required per assembly: 3 Currently Not Available
7	WELD-BRKT, CLOCKSPRING, E-COAT Part #: 1019452-329 Required per assembly: 1 Currently Not Available
8	ASM-STEERING, COLUMN, MY18 Part #: 1824731 Required per assembly: 1 Currently Not Available
8	ASSEMBLY, STEERING, COLUMN, INTL Part #: 1824452 Required per assembly: 1 Note: INTL ONLY Currently Not Available
9	SCR-HXFL-M8X1.25X16 8.8 ZOD Part #: 7519181 Required per assembly: 4 Currently Not Available
10	NUT-HEX-M20X1.5 8 ZOD Part #: 7547668 Required per assembly: 1 Currently Not Available
11	BUSHING, STEERING Part #: 7556675 Required per assembly: 2 Currently Not Available
12	SHAFT, STEERING, EPS, LOCK Part #: 1824463 Required per assembly: 1 Note: INTL Currently Not Available
12	SHAFT, STEERING, EPS Part #: 1824551 Required per assembly: 1 Currently Not Available
13	ASM-POWER, STEERING, SLINGSHOT Part #: 2414264 Required per assembly: 1 Currently Not Available
14	NUT, NYLOK Part #: 7547385 Required per assembly: 2 Currently Not Available
15	SCREW Part #: 7518644 Required per assembly: 3 Currently Not Available
16	SCREW Part #: 7518291 Required per assembly: 2 Currently Not Available
17	NUT-HEX-M10X1.5 10 ZB3 NYL Part #: 7547746 Required per assembly: 2 Currently Not Available
18	ROD-END, 10MM, 1/2-20LH Part #: 7061224 Required per assembly: 2 Currently Not Available
19	NUT, LH, JAM Part #: 7547028 Required per assembly: 2 Note: Nut, Jam, LH ~~$3.99~~ $2.30 - + Add to cart
20	SCR-HEXHD, M8X20, ZINC, 0600088 Part #: 7518097 Required per assembly: 2 Currently Not Available
21	BOOT, PASSENGER, SIDE, RACK Part #: 5412013 Required per assembly: 2 Currently Not Available
22	SCREW Part #: 7517792 Required per assembly: 4 Currently Not Available
23	RACK-STEERING, 17T, SPLINE Part #: 1824432 Required per assembly: 1 Currently Not Available
24	ASM-COUPLING, FLEX, EPS Part #: 1824415 Required per assembly: 1 Currently Not Available
25	SCREW Part #: 7518558 Required per assembly: 4 Note: Bolt, Flange Currently Not Available
26	BRKT-EPS, STIFFENER Part #: 5260341 Required per assembly: 1 Currently Not Available
27	SCREW Part #: 7519727 Required per assembly: 2 Currently Not Available
28	CLAMP, BOOT, LARGE Part #: 7080979 Required per assembly: 2 Currently Not Available
29	CAM-TURN, SIGNAL, CANCEL Part #: 5452091 Required per assembly: 1 Currently Not Available
