Wire Harness replacement parts for 2021 Polaris Ranger 1000XP PS MUD (R02)

OEM Parts Polaris 2021 Polaris Ranger 1000XP PS MUD (R02) Wire Harness

WIRE HARNESS Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	HARN-CHASSIS, BC Part #: 2415394 Required per assembly: 1 Note: INCL. 2-14,36-42 Currently Not Available
2	RELAY-SPST, 12V, 20A, EPXY, HFA Part #: 4016819 Required per assembly: 9 Currently Not Available
3	FUSE-20 MINI BLADE 58V(YELLOW) Part #: 4012811 Required per assembly: 3 Currently Not Available
4	DECAL-RELAY/FUSE, BLOCK, LE, RC Part #: 7300225 Required per assembly: 1 Currently Not Available
5	CLIP-ROUTING Part #: 7081496 Currently Not Available
6	CLIP, PLASTIC, DART, NYLON Part #: 7670090 Required per assembly: 4 Note: Clip, Dart ~~$2.99~~ $1.73 - + Add to cart
7	COVER, DIAGNOSTIC, W/CLIP Part #: 4012170 Required per assembly: 1 Currently Not Available
8	FUSE, 10AMP Part #: 2434016 Required per assembly: 3 Note: Fuse, 10 AMP, Ignition Sold in multiples of 10 only Currently Not Available
9	BREAKER, CIRCUIT, 20, AMP Part #: 2410881 Required per assembly: 1 Currently Not Available
10	GROMMET Part #: 5814560 Required per assembly: 1 Currently Not Available
11	FUSE, MAIN, 30, AMP Part #: 2434015 Required per assembly: 1 Note: Fuse, 30 AMP, Main Sold in multiples of 10 only Currently Not Available
12	FUSE, MINI, BLADE, 15, AMP. Part #: 4010859 Required per assembly: 3 Currently Not Available
13	COVER-FUSEHOLDER Part #: 4012260 Required per assembly: 1 Currently Not Available
14	GROMMET-USB, 3, MM, 22, MM, DIA Part #: 5415308 Required per assembly: 1 Currently Not Available
15	STRAP PANDUIT Part #: 7080138 ~~$1.99~~ $1.15 - + Add to cart
16	SCR-TFHFL-M6X1.0X25, ZY3 Part #: 7520715 Required per assembly: 8 Currently Not Available
17	KIT, IGNITION, COIL Part #: 2876049 Required per assembly: 1 Note: Coil Currently Not Available
18	BRKT-COIL MOUNT Part #: 5263891 Required per assembly: 1 Currently Not Available
19	SPACER, COIL Part #: 5436577 Required per assembly: 1 Note: Spacer, Coil Mount Currently Not Available
20	SCREW Part #: 7518529 Required per assembly: 8 ~~$2.99~~ $1.73 - + Add to cart
21	SCREW Part #: 7518780 Required per assembly: 1 Currently Not Available
22	NUT Part #: 7547274 Required per assembly: 2 Note: Nut, Flange Currently Not Available
23	BLOCK-TERMINAL, 6, POS Part #: 4016007 Required per assembly: 1 Note: INCL. FUSE PLUG AND COVER Currently Not Available
24	ECM Part #: 4014125 Required per assembly: 1 Currently Not Available
25	SCREW Part #: 7519091 Required per assembly: 4 Currently Not Available
26	HARNESS, BOX, RANGER, RC Part #: 2414296 Required per assembly: 1 Currently Not Available
27	SCREW Part #: 7519731 Required per assembly: 8 Currently Not Available
28	BRKT-ROUTING, BLK Part #: 5264313-329 Required per assembly: 1 Note: TO 9/12/2020 Currently Not Available
28	BRKT-ROUTING, BLK Part #: 5268050-329 Required per assembly: 1 Note: FROM 9/12/2020 Currently Not Available
30	GROMMET-HOOD, LINER, SPLIT Part #: 5417082 Required per assembly: 1 Currently Not Available
31	BRKT-MOUNT, REG Part #: 5263643 Required per assembly: 1 Currently Not Available
32	REGULATOR-3PH, 50A, SERIES, HISPD Part #: 4016868 Required per assembly: 1 Currently Not Available
33	BRKT-FUSE, BLOCK, MNT, BLK Part #: 5264801-329 Required per assembly: 1 Currently Not Available
34	RIVET Part #: 7661855 Required per assembly: 2 ~~$2.99~~ $1.73 - + Add to cart
35	SCREW Part #: 7518555 Required per assembly: 4 Note: Bolt, Flange Currently Not Available
36	FUSE, 7.5, AMP Part #: 4011068 Required per assembly: 2 Currently Not Available
37	RELAY-SSR 10A Part #: 4018251 Required per assembly: 2 Currently Not Available
38	CAP-VINYL, 125X375, BLACK Part #: 5438230 Required per assembly: 1 Currently Not Available
39	STRAP-CABLE TIE W/EDGE CLIP Part #: 7081808 Required per assembly: 2 Currently Not Available
40	CLIP-EDGE, HARNESS Part #: 7081890 Required per assembly: 3 Currently Not Available
41	CLIP-EDGE, 3-6MM, THICKNESS Part #: 7082404 Required per assembly: 1 Currently Not Available
42	CLIP-EDGE, 1-3MM, THICKNESS Part #: 7082428 Required per assembly: 2 Currently Not Available
43	CAP-REGULATOR, DC Part #: 5456378 Required per assembly: 2 Currently Not Available
44	HARN-WINCH, CONT, JMPR Part #: 2415993 Required per assembly: 1 Currently Not Available
45	CLIP-CONNECTOR, GREY Part #: 4018311 Required per assembly: 2 Currently Not Available
46	BRKT-REGULATOR, MTNG, CAP, BLK Part #: 5268319-329 Required per assembly: 1 Currently Not Available
47	BRKT-MOUNT, REG Part #: 5267612 Required per assembly: 1 Currently Not Available
