System Case replacement parts for 2000-2006 BMW R1150RT (R22)

OEM Parts Bmw 2000-2006 Bmw R1150RT (R22) System Case

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

02	SYSTEM CASE RIGHT WITHOUT CYLINDER - 31L Part #: 46547660300 Required per assembly: 1 Currently Not Available
02	SYSTEM CASE LEFT WITHOUT CYLINDER - 32L Part #: 46542317611 Required per assembly: 1 Currently Not Available
03	BOTTOM PART RGHT WITHOUT MULTIFUNCT.BOX Part #: 46542317620 Required per assembly: 1 Currently Not Available
03	BOTTOM PART LEFT WITHOUT MULTIFUNCT.BOX - GID Part #: 46542317619 Required per assembly: 1 Currently Not Available
04	COVER LEFT - SAPHIRE BLACK Part #: 46547689299 Required per assembly: 1 Currently Not Available
04	COVER RIGHT - SAPHIRE BLACK Part #: 46547689300 Required per assembly: 1 Currently Not Available
04	COVER LEFT - BLACK/GENARBT Part #: 46542317615 Required per assembly: 1 Currently Not Available
04	COVER RIGHT - BLACK/GENARBT Part #: 46542317616 Required per assembly: 1 Currently Not Available
05	SET: SET OF SUITCASE LOCKS WITH CODE Part #: 51252307617 Required per assembly: 1 Not Available
05	SET: SET OF SUITCASE LOCKS Part #: 51252307618 Required per assembly: 1 Currently Not Available
08	BADGE Part #: 46542300045 Required per assembly: 2 Currently Not Available
09	REFLECTOR, RED Part #: 46542300047 Required per assembly: 2 Note: FOR VEHICLES WITH SWITZERLAND VERSION Currently Not Available
09	REFLECTOR, YELLOW Part #: 46542300134 Required per assembly: 2 Note: FOR VEHICLES WITH NATIONAL VERSION CHINA (CODE: Y770A) Currently Not Available
10	EMBLEM - TOURING Part #: 46542300046 Required per assembly: 2 Currently Not Available
