Air Intake System - R17rt_99 All Options (700398) replacement parts for 2017 Polaris Ranger 1000 XP All Options (R30)

OEM Parts Polaris 2017 Polaris Ranger 1000 XP All Options (R30) Air Intake System - R17rt_99 All Options (700398)

AIR INTAKE SYSTEM - R17RT_99 ALL OPTIONS (700398) Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	ASSEMBLY, AIRBOX, LID Part #: 1240625 Required per assembly: 1 Note: INCL. 1-4 Currently Not Available
2	BUSHING, FLANGE Part #: 5137652 Required per assembly: 3 Currently Not Available
3	GROMMET, BASE, TOP Part #: 5414160 Required per assembly: 3 Currently Not Available
4	ASSEMBLY, AIRBOX, LID Part #: 1240625 Required per assembly: 1 Currently Not Available
5	ASSEMBLY, AIRBOX, MAIN Part #: 1240787 Required per assembly: 1 Note: INCL. 6,7 Currently Not Available
6	BASE, AIRBOX Part #: 5450722 Required per assembly: 1 Note: M99AM,BM Currently Not Available
6	BASE, AIRBOX Part #: 5450722 Required per assembly: 1 Note: E99AS,BS,AW,BW AY,BY,A9,B9 Currently Not Available
7	CLIP-AIRBOX Part #: 7081707 Required per assembly: 5 Currently Not Available
8	BRACKET, AIRBOX, MOUNT Part #: 5255273 Required per assembly: 1 Currently Not Available
9	HOSE-INTAKE, ENG Part #: 5415594 Required per assembly: 1 Currently Not Available
10	HOSE, VENT, ENGINE Part #: 5414331 Required per assembly: 1 Currently Not Available
11	HOSE, INTAKE, AIRBOX Part #: 5414543 Required per assembly: 1 Currently Not Available
12	CLAMP, HOSE Part #: 7080446 Required per assembly: 3 Currently Not Available
12	CLAMP, HOSE Part #: 7080446 Required per assembly: 3 Currently Not Available
12	CLAMP, HOSE Part #: 7080446 Required per assembly: 3 Currently Not Available
12	CLAMP, HOSE Part #: 7080446 Required per assembly: 3 Currently Not Available
13	CLAMP, HOSE, Part #: 7080614 Required per assembly: 1 Note: Clamp, Hose Currently Not Available
14	CLAMP, SPRINGBAND Part #: 7080841 Required per assembly: 1 Currently Not Available
15	FILTER-AIRBOX MAIN Part #: 7081706 Required per assembly: 1 Currently Not Available
16	SCREW Part #: 7518529 Required per assembly: 2 ~~$2.99~~ $1.73 - + Add to cart
17	SCR-TFHFL-M6X1.0X25 ZOD Part #: 7519342 Required per assembly: 3 ~~$4.04~~ $2.91 - + Add to cart
18	PLUG, DRAIN Part #: 5414472 Required per assembly: 2 Note: INCL ALL EXCEPT AM,BM Currently Not Available
19	SCREW Part #: 7518238 Required per assembly: 4 Note: INCL ALL EXCEPT AM,BM ~~$3.79~~ $1.73 - + Add to cart
20	HOSE, INTAKE, BOOT Part #: 5414542 Required per assembly: 1 Note: INCL ALL EXCEPT AM,BM Currently Not Available
21	FENDER, INTAKE, REAR, BLACK Part #: 5439201-070 Required per assembly: 1 Note: INCL ALL EXCEPT AM,BM Currently Not Available
22	DUCT, INTAKE, AIR Part #: 5439947 Required per assembly: 1 Note: INCL ALL EXCEPT AM,BM Currently Not Available
23	CLAMP, HOSE Part #: 7080439 Required per assembly: 2 Currently Not Available
23	CLAMP, HOSE Part #: 7080439 Required per assembly: 2 Currently Not Available
24	PLUG-DRAIN, HC Part #: 5139797 Required per assembly: 1 Note: M99AM,BM Currently Not Available
25	HOSE-INLET HC Part #: 5415215 Required per assembly: 1 Note: M99AM,BM Currently Not Available
26	SEAL-ENGINE, INTAKE, MUDDER Part #: 5415625 Required per assembly: 1 Note: M99AM,BM Currently Not Available
27	PLUG-AIR, BOX, MUDDER Part #: 5415705 Required per assembly: 1 Note: M99AM,BM Currently Not Available
28	DUCT-INTAKE, ENGINE, MUDDER Part #: 5452495 Required per assembly: 1 Note: M99AM,BM Currently Not Available
29	SCR-TXPH-#10X1.0 ZPB HI/LO Part #: 7520164 Required per assembly: 4 Note: M99AM,BM Currently Not Available
30	CVR-PLAST, INTAKE, HOSE, TOP, V, BL Part #: 5451616-689 Required per assembly: 1 Note: M99AM,BM Currently Not Available
31	CVR-PLAST, INTAKE, HOSE, BTM, BLK Part #: 5451617-070 Required per assembly: 1 Note: M99AM,BM Currently Not Available
